TW35 Adaptive Variable Frequency Permanent Magnet Booster Pump
R2,070.00
Protection: TW35
Adaptive Variable Frequency
Permanent Magnet
Booster Pump for Wholehouse
✅ In Stock — Ready to Ship
The TW35 Booster Pump utilizes advanced technology to provide consistent water pressure across all fixtures in your home. Its adaptive variable frequency drive adjusts the motor speed to match water demand, optimizing energy consumption. The permanent magnet motor offers high efficiency and durability, ensuring long-term reliability.
This pump is ideal for boosting water pressure in multi-story homes, supporting reverse osmosis systems, or enhancing flow in irrigation systems. Its compact design allows for easy installation, and its quiet operation makes it suitable for residential environments.
Key Features
- Adaptive Variable Frequency Control: Adjusts motor speed to match water demand, optimizing energy use.
- Permanent Magnet Motor: Provides high efficiency and durability.
- IP55 Protection Rating: Dust-tight and protected against water jets, suitable for indoor or sheltered outdoor installation.
- Quiet Operation: Designed for low noise levels, enhancing residential comfort.
- Easy Installation: Compact design allows for straightforward setup.
Specifications
- Model: TW35
- Motor Type: Permanent Magnet
- Control Type: Adaptive Variable Frequency
- Protection Rating: IP55
- Noise Level: Low
Key Features
1. Wide input voltage range
- 100-140V,50/60Hz
- 160-240V,50/60Hz
2. DC 24-40V output voltage
- Human safe voltage, no risk of use
3. Adaptive function
- Automatically identify the pipe pressure
- Automatically regulates the starting pressure
4. Super long life span
- S1 motor duty cycle, 30,000 hours of service life
5.Anti-freezing&pressure resistance
- Small impeller, a small pump body.higher hardness
6. Super quiet 20-30dB
- Adopt a permanent magnet motor and a water cooling structure, which doesn’t need a cooling fan
7. Worth investing in and making brand Fourinvention patents, exclusive technology
8. Energy saving 70%
- 160W permanent magnet motor
9.Max.suction is 9m, wider application range
10. Zero rust water fluid passage components are made of food-grade plastic
11. Dual control system(pressure + flow switch)
- Support step-less pressure regulation for a pump with 0-100m head
12. Multiple protection
- Water shortage protection, frequent start&stop protection,overcurrent&undervoltage protection, etc.
13. Timing function, supply water for the water tower
14. Plug and play
15. High pass rate of standard parts and high production efficiency
- Customized model for each part, no finishing, one cross screwdriver completes assembly and disassembly
Working Condition
- Liquid temperature:0-100°C
- Ambient temperature:4-55°C
- Max.suction:+9m
- Insulation: Class H
- Ingress protection: IP55
- Duty cycle: S1
- Input voltage: Single phase
- 100-140V，50/60Hz
- 160-240V,50/60Hz
Performance Chart
Technical Data
| Model | Voltage （V） | Power (W) | Power (HP) | Max.flow （m³/h） | Max.flow （L/min） | Max.head （m） | Max.suction （m） | PIPE （mm) |
| TW35 | DC-40 | 160 | 0.2 | 2.5 | 42 | 35 | 9 | 1″×1″ |
FAQ
- Q1: How does the adaptive variable frequency control work?
A1: The control adjusts the motor speed based on real-time water demand, ensuring efficient operation and consistent water pressure. - Q2: Can this pump be used for multi-story homes?
A2: Yes, the TW35 Booster Pump is ideal for boosting water pressure in multi-story homes. - Q3: Is the pump suitable for outdoor installation?
A3: With its IP55 protection rating, the pump can be installed in sheltered outdoor locations. - Q4: What maintenance does the pump require?
A4: The TW35 Booster Pump requires minimal maintenance. Regular checks and cleaning are recommended to ensure optimal performance.
