Gel Battery GE100-12 200AH 12V
Nationwide Delivery · Genuine & Warrantied · Easy Returns · Secure Checkout
Gel Battery GE100-12 200AH 12V
GE200-12 12V 100Ah Gel Battery – Deep Cycle Power
Description of 12V 200Ah GEL Battery
The GE200-12 Gel Battery delivers reliable 12-volt power with a 100-amp-hour deep-cycle capacity, making it ideal for solar setups, UPS backup, and off-grid applications. With its sealed gel-electrolyte design, you’ll benefit from maintenance-free performance and long service life.
The GE200-12 Gel Battery features advanced gel-battery technology to provide dependable deep-cycle capacity in demanding environments. Because it uses a sealed gel design, it resists leaks, handles tough conditions, and reduces maintenance. Its 12 V/100 Ah rating suits renewable energy systems, standby power, and frequent discharge-recharge use.
Moreover, the design includes thick plates and high-density active materials for better recovery after deep discharges. The GE series also meets international standards for reliability and long life, making it a strong choice for both residential and commercial applications.
Key Features
- 12 V nominal voltage with 100 Ah capacity at 10-hour rate.
- Sealed gel deep-cycle construction — maintenance-free and non-spillable.
- Excellent recovery after deep discharge due to robust internal structure.
- Suitable for solar power systems, UPS, telecom, standby or frequent use.
Specification
| Specification | Value |
|---|---|
| Model | GE200-12 |
| Nominal Voltage | 12 V |
| Rated Capacity (10h) | 100 Ah |
| Construction | Sealed Gel / VRLA |
| Service Life | Up to 10 years (float use) |
| Application | Solar, UPS, standby power |
- Rated Voltage: 12V
- Number of cells: 6 Cells
- Capacity: 200Ah @10hr rate to 1.80V Per Cell @25˚C
- Weight: 62.4kg
- Internal Resistance: Approx. 3.5mΩ
- Terminal: F1 / F2
- Max. Discharge Current: 3 00A(5s)
- Short Circuit Current: 10000A
- Max. Charging Current: 50A
- Reference Capacity: C10 200.0AH | C3 144.7AH | C1 110.1AH
- Design Life: 10~15 years
- Float Charging Voltage: 13.6 V~13.8 V @ 25°C
Temperature Compensation: -20mV/°C/Cell
- Cycle Use Voltage: 14.4 V~14.9 V @ 25°C
Temperature Compensation: -30mV/°C/Cell
- Operating Temperature Range: Discharge: -20°C~60°C | Charge: 0°C~50°C | Storage: -20°C~60°C
- Normal Operating Temperature Range: 25°C±5°C
- Self Discharge: Less than 3% at 25°C per month
- Container Material: A.B.S. UL94-HB, UL94-V0 Optional.
Gel Battery Specification
FAQ
-
Q1: What does “deep cycle” mean for this battery?
A1: “Deep cycle” means the battery is designed to be regularly discharged and recharged, making it ideal for solar storage and backup power systems. -
Q2: Is the GE200-12 maintenance-free?
A2: Yes. The sealed gel construction means you do not need to add water or service the battery regularly. -
Q3: Can this battery handle harsh conditions?
A3: Yes. The gel technology and thick plate construction provide better durability and recovery in tough environments. -
Q4: Can I use this battery in a solar system?
A4: Absolutely. Its 12 V and 100 Ah rating make it a solid choice for solar applications and standby power.
